ADF4351 RF Signal Generator 35MHz-4400MHz Frequency Output, Type-C Powered, For SMA Port, 1KHz-1MHz Adjustable Step For Electronics Testing

Features:1. Support USB power supply, wide output frequency range (35MHz-4400MHz), meeting various application scenarios.2. Built-in simple RF signal source generator, convenient for testing frequency-amplitude characteristics of equipment AC .3. The operation keyboard is user-friendly, and 15 function keys support precise frequency adjustment and transmission control.4. Provide four step modes (1K/10K/100K/1M), which is convenient for fast or fine adjustment of frequency output.5. Low power consumption design, standby current is less than 25mA, suitable for long-term use and portable applications.Specifications:Product name: RF signal generatorMaterial: PCB board, metalColor: greenSize: 80mm*75mm*30mm (excluding interface)Power supply interface: Type-CPower supply voltage: DC 4.5V-5.5VStandby current: <25mATransmitting current: <150mAOutput impedance: 50 ohmsOutput frequency range: 35MHz-4400MHzOutput step: 1KHz-8KHzOutput: For SMA standard interface inner holeOutput power: -1dBm (W) @ 150MHZ (test power absolute value) about 1 for mWPackage Content:1*RF signal generator1*antenna

• Wide Frequency Range: Covers 35MHz-4400MHz for broad testing applications in RF design, troubleshooting, and educational experimentation, giving versatility from low VHF to high microwave bands for both lab and field use.
• Convenient Operation: RF Signal Generator 35MHz-4400MHz Signal Source Frequency Screen kit, Equipped with 15 intuitive function keys and four step modes (1K/10K/100K/1M) for rapid or fine frequency tuning, allowing precise control during calibration or performance evaluation tasks.
• Portable Power via Type-C: Supports DC 4.5V-5.5V USB supply through a TypeC interface, enabling easy connection to power banks or workstations, with standby current below 25mA for long lasting outdoor or mobile use.
• Stable Output Mechanism: For SMA standard interface with 50-ohm impedance and output power about -1dBm @150MHz delivers consistent RF frequency generator performance, helping forestall signal instability in sensitive equipment tests.
• Complete Package: Includes RF signal generator and antenna, built with PCB board and metal housing measuring 80mm*75mm*30mm, ready to integrate into your RF toolkit for professional measurement and signal source tasks.
